AS-BAND HIGH POWER PULSED KLYSTRON USED IN ELECTRON LINEAR ACCELERATORS

Abstract
HTML
Reference
Related

PDF

Abstract：
A S-band high-power pulsed klystron is described in this paper. This klystron operates at 2856 MHz, 250 kV and 200 A. Its measured pulsed power exceeds 15 MW with efficiency higher than 40% and gain greater than 40 db. This tube has been used routinely on a 30 MeV Electron Linear Accelerator with reliable performance.
In this paper, the design requirements, the design considerations, the measured results and the problems encountered are discussed.
