Development of Synchrotron Radiation X-Ray Grazing Incident Diffraction Method

Institute of High Energy Physics, CAS, Beijing 100039, China1 Surface Physics National Key Lab., Fudan University, Shanghai 200433, China

Abstract
HTML
Reference
Related

PDF

Abstract：
Synchrotron radiation X-ray grazing incident diffraction (GID) method was developed based on the five-circle diffractometer in the Diffuse Scattering Station at Beijing Synchrotron Radiation Facility. The lateral strain induced by the Ge/Si quantum dotswas measured successfully, which showed the capability of the GID method in measuring weak signals from surface structures. The results showed that the formation of Ge/Si quantum dots caused both the lateral expansion-strain and contraction-strain in the surface layer of Si(001) substrate.
