Experimental Investigations on the Resonator Mirrors of SR-FEL and ICF KrF Laser

Institute of Electronics,CAS,Beijing 100080,China2 China Institute of Atomic Energy,Beijing 102413,China

Abstract
HTML
Reference
Related

PDF

Abstract：
For storage–ring free electron laser (SR-FEL) and KrF laser driver of inertial confinement fusion(ICK KrF Laser), the mechanism of laser production is fully different from each other, but they have a nearly same requirement to the resonator mirror. The multi–layer interference coatings of the resonator mirror must suit for ultra–violet and extreme ultra–violet laser, and have a high reflectivity, wide frequency band, stable optical properties, long life–time. Today, a resonator mirror, consisting of oxides and fluoride (al ₂O ₃/SiO ₂/MgF ₂),has been developed successfully.Its optical reflectivity at 248nm reaches up to 96.83%, its frequency band–width is larger than 19.5nm, and its damage–resistant threshold is (5.36±0.30)J/cm ²to 23ns pulsed laser at 248nm. It will be able to be applied to the tunable high power SR-FEL and kJ ICF Krf laser.

References

[1]

. Patrick G O'Shea, Henry P Freund. Science, 2001, 292( 8, June) :1853-18582. Andruszkow J et al . Phys. Rev. Lett . , 2000, 85: 38253. Mike Poole. Science, 1996, 272( 26 April) : 467-4714. Heber J et al. Fraunhof er IOF Annual Report, 2001, 325. YU L H et al. Science, 2000, 289 (11 August ) : 9326. Milt on S V et al. Science, 2001, 292( 15 June) : 20377. Tremaine A, WANG X J, Babzien M et al. Phys. Rev. Lett. , 2002,88( 20) : 204801-1-204801-48. Alexandre Gatto et al. Appl . Opt . , 2002, 41(16) : 32369. Hosaka M, Koda S, Katoh M et al. Proc. Second Asian ParticleConf . , Beijing, 2001. 296- 29810. Yamada K, Sei N, Ohgaki H et al. Nucl. Instrum. Methods Phys.Res. , 2000, A445: 173- 17711. Litvinenko V. Nucl . Instrum. Methods Phys. Res. , 1999, A429:151-15812. Gatto A, Feigl T, Kaiser N et al. Nucl . Instrum. Methods Phys.Res. , 2002, A483: 172 -17613. Gatts A, Heber J, Kaiser N et al. Nucl. Instrum. Methods Phys.Res. , 2002, A483: 357 - 36214. Obenschain S P et al. Phys. of Plasmas, 1996, 3( 5) : 209815. Taniguchi J et al. Proc. SPIE, 2001, 4347: 10916. GAO Huai-Lin, SHAN Yu-Sheng, WANG Nai-Yan. Chinese J. Laser,1997, B6( 3) : 229 - 23717. GAO Huai-Lin, SHAN Yu-Sheng, WANG Nai-Yan. Opt . Tech. ,1997, 6: 23 -26(in Chinese)(高怀林，单玉生，王乃彦.光学技术，1997 , 6: 23-26)
