Study on High Order Modes of a β=0.45,f=350MHz Spoke Cavity

Institute of Heavy Ion Physics, Peking University, Beijing 100871, China

Abstract
HTML
Reference
Related

PDF

Abstract：
Intensive study has been done on low and medium energy section of proton and heavy ion accelerators. Many experiments show that spoke cavity is a very good candidate to connect low beta RFQ (radio frequency quadrapole) structure and high beta elliptical accelerating structure. A β=0.45, f=350MHz spoke cavity has been designed and a copper model spoke cavity has been fabricated at Peking University. In this paper, we put the emphasis on the analysis of HOMs (high order modes) of the spoke cavity.
