APPLICATION OF PERMANENT MAGNET LENSES IN ACCELERATORS BEAM TRANSPORT AND FOCUSING

Abstract
HTML
Reference
Related

PDF

Abstract：
This paper presents the characteristics, structure and parameters of the permanent magnet quadrupole lenses which have been used as a beam transport element in our linac. The methods of connection and adjustment are discussed. After transporting 15MeV electron beams by 43cm, a improvement of 50%—80% of the primary beam profile was obtained.
