EPR Studies on Defect Production and lts Annealing Behavior in Silicon After High Fluence Ar lon lrradiation

Institute of Modern Physics,The Chinese Academy of Sciences,Lanzhou 730000

Abstract
HTML
Reference
Related

PDF

Abstract：
Silicon samples were irradiated below 50K with 1 12MeV Ar ions to a fluence of 8×10 ¹⁴/cm ². Defect production and its isochronal annealing behavior have been investigated at room temperature by Electron Paramagnetic Resonance technique. Neutral 4-vacancy (Si-P3 center), positively charged 〈100〉 splitted di-interstitial (Si-P6 center) and the contiuous amorphous layer have been detected in the as-irradiated sample. At an annealing temperature of 200℃ , the Si-P3 and Si-P6 centers were annealed out and five vacancy cluster in negative charge state (Si-P1 center) began to grow. The Si-P1 center disappeared at about 550℃. For the temperature above 350℃, Si-A11 center (a center may include several vacancies) has been observed, which was stable up to 550℃, The temperatue for recrystallization of the continuous amorphous layer is higher than 600℃. During the annealing process, the line shape and line width for amorphous center were not changed. The results are qualitatively discussed.

References

[1]

Dennis J R, Hale E B. J. Appl. Phys., 1978, 49(3): 1119-1127[2] Murakami K, Masuda K, Gano K et al. Japan J. Appl. Phys., 1973, 12(9): 1307-1316[3] Cheng L J, Corelli J C, Corbett J W et al. Phys. Rev., 1966, 152(2):761--774[4] Varichenko V S, Zaitsev A M, Melnikov A A et al. Nucl. Instrum. Meths., 1994, B94:259-265[5] Nsenoff N, Fan H Y. Phys. Rev., 1962, 128(4): 1605-1613[6] Wun Jung, Newell G S. Phys. Rev., 1963, 132(2):648-662[7] Ohdomari I, Ikeda M, Yoshimoto H et al. Proc. Inter. Conf. on Ion Implantation in Semiconductor,Boulder Colordo: 1976, P39-46[8] Lee Y H, Gerasimenko N N, Corbett J W. Phys. Rev., 1976, B14:4506-4519[9] Lee Y H, Brosious P R, Corbett J W. Rad., Effs., 1974, 22: 169-172[10] Bogdanski P, Mary P, Toulemonde M. Nucl. Instrum. Meths., 1992, B62: 388-390[11] Liu Changlong, Hou Mingdong, zhu Zhiyong et al. High Energy Physics and Nuclear Physics, (in Chinese),1998, 22(9)(刘昌龙,侯明东,朱智勇等。高能物理与核物理,1998,22(9))
