A MULTIPLE HIT TIME-TO-DIGITAL CONVERTER

Abstract
HTML
Reference
Related

PDF

Abstract：
A time-to-digital converter with the multiple hit capacity is described using a ECL random access memory (RAM) E859. It is able to process up to≤128 hits per signal wire for 8 wires of the drift chamber with full scale time range 2.56μs and time resolution 10ns, which corresponds to space resolution～210μm.
