Chinese Physics C > 1991, Vol. 15 > Issue(4): 289-297

1GeV/c Wide Range Magnetic Spectrometer

Institute of High Energy Physics,Academia Sinice,Beijing 100039

Abstract
HTML
Reference
Related

PDF

Abstract：
The structure of an 1GeV/c wide-range magnetic spectrometer is briefly described.The spectrometer includes the magnet system and the detector & data acquisition system.The momentum formula at extended edge field case for non-focusing magnetic spectrometer has been derived.The momentum resolution,solid angle,momentum acceptance and other parameters for this spectrometer are calculated by Monte Carlo simulation.The effects of the multiple scattering and position resolution of the detectors to momentum resolution of this spectrometer are discussed.

References

[1]

中国科学院高能物理所，22/28亿电子伏正负电子对撞机初步设计概要(1982,12).[2] R. Anderson et al. Nucl. Instr. and Meth., 66 (1968), 328; H. Ehrenberg et al, Nucl. Instr.and Meth., 105 (1972), 253; P. Leconte et al, Nucl. Instr. and Meth., 169 (1980), 401; W. Be-rtogg et al, Nucl. instr. and meth., 162 (1979), 211.[3] 毛振麟,“一个为中能电子散射用的广量程磁谱仪”,高能物理与核物理,12 (1988),298.[4] 陈绍兴、王功利、王子华、邢炎、毛振麟,“电子散射磁谱仪磁铁电源的远距离程控和监察系统”,原子能科学技术,即将分宪。[5] 王子华等,核技术,14(1991),193.[6] H. Enge, "Focusing of charged particles" Vol. 2.[7] 邢炎,“用于非聚焦型广量程磁谱仪的高分辨小型多丝室系统、研究生论文(1989, 9).[8] 后晓江、邢炎、毛振麟,“用于电子散射实验的小型多丝室电子学系统”,核电子学与探测技术，即将发表.[9] 何英、张勤俭、后晓江、王辉、王功利、毛振麟,“用于电子散射谱仪的多丝漂移室”,内部报告(1990, 3).[10] 后晓江,“左右甄别CAMAC插件LRD"}怪国第五次核电子学和探测器会议文集(1990.8).[11] 张勤俭,“用于电子散射磁谱仪的定时探测器”,内部报告(1987, 10).[12] 张勤俭,“用于电子散射磁谱仪的铅玻璃簇射计数器”,内部报告(1990,2).
