Chinese Physics C > 2006, Vol. 30 > Issue(8): 802-805

Simulation of Thermal Distortion of DCM Crystal Indirectly Cooled by LN₂

Shanghai Institute of Applied Physics, CAS, Shanghai 201800, China

Abstract
HTML
Reference
Related

PDF

Abstract：
The simulation result of thermal distortion of DCM crystal indirectly cooled by liquid nitrogen(LN ₂) at Shanghai synchrotron radiation facility (SSRF) has been reported. The source is U27 undulator. The maximum of power density at 24m is 60W/mm ². We give the correlation of the slope error of crystal surface vs. Bragg angle, the convection film coefficient, the bulk temperature of LN ₂and total power absorbed by the first crystal, respectively. The slope error is less than 3 arcsec when the Bragg angle is less than 30°, the thickness of crystal is larger than 30mm, the current of storage ring is up to 400mA and cooled by 78K LN ₂.

References

[1]

. Donald H. Bilderback, Andreas K. Freund, Gordon S.Knapp et al. J. Synchrotron Rad., 2000, 7: 53-602. ZHANG Lin, Lee Wah-Keat. J. Synchrotron Rad., 2003,10: 313-3193. Lee Wah-Keat, Kamel Fezzaa, Patricia Fernandez et al. J.Synchrotron Rad., 2001, 8: 22-254. ZHANG Lin. Proc. SPIE 1993. 1997, 223-2355. WANG Na-Xiu et al. Nuclear Technique, 2002, 25(6):401-407(in Chinese)(王纳秀等.核技术,2002,25(6):401—407)
