Multilayer Polarizing Elements for Synchrotron Radiation Soft X-Ray Region

Institute of High Energy Physics,CAS,Beijing 100039,China2 Institute of Precision Optical Engineering,Department of Physics,Tongji University,Shanghai 200092,China

Abstract
HTML
Reference
Related

PDF

Abstract：
Periodic multilayers of W/C and Mo/Si have been developed with magnetron sputtering technology.The parameters of period and thickness are adjusted so that the first Bragg peak appears at the Brewster angle when the photon energy is in the vicinity of K edge of carbon and L edge of silicon respectively.The experiment was implemented at Beijing Synchrotron Radiation Facility(BSRF).The reflectivities of multilayer Mo/Si and W/C can reach 32.3% at 89eV and 4.18% at 214eV respectively near the Brewster angle.The feasibility of setting up polarizer with multilayers is discussed in this paper.
