Preliminary Experiment on Beam-Based Alignment

Institute of High Energy Physics, CAS, Beijing 100039, China

Abstract
HTML
Reference
Related

PDF

Abstract：
The offset of the beam position monitor (BPM) with respect to the magnetic center of the quadrupole can be determined by the method of the beam-based alignment. The BPM alignment accuracy can be improved by one order of magnitude compared with conventional surveying techniques. This paper gives a brief intreduction to the principle of the beam-based alignment and the description of the preliminary experiment performed on the BEPC storage ring. The considerations of the further experiments are also given.
