STUDIES OF THE FOCUSING PROPERTIES OF A SPACE CHARGE LENS

Abstract
HTML
Reference
Related

PDF

Abstract：
A space charge lens has been designed and tested which can be used to focus intense ion beams at several tens of keV. The experimental results obtained can be interpreted with a simplified physical model. The existence of a space charge field and its strong focusing properties are tested experimentally. And it is shown that the relaxation time for the formation of space charge field is much less than 10 μs under our experimental conditions, thus the lens can be used to focus pulsed beams with length of several hundereds of μs of longer.

References

[1]

B.Von Bowies, E. Ruaka, Z. Physik, 76(1932),649.[2] D. Gabor, Nature, 160(1947), 89.[3] А. И. Мороэов, Док. Акα Нαyк СССР., 163(1965), 1963.[4] С. В. Лебедев, А. И. Мороэов, Ж. Т. Ф., 36(1966), 960.[5] R. Booth, H. W. Lefevre, N. 1. M., 151(1978), 143.[6] H.W.Lefecre, R, Booth, IEEE. Trans., NS26(1979), 8115.[7] R. M. Mobley, G. Ganunel, A. W. Masehke, IEEE. Trans., N526(1979), 3112.
