Chinese Physics C > 2001, Vol. 25 > Issue(5): 448-454

Calibration of Energy Response of Detection Elements for Soft X-Ray Spectrometer

Laboratry for Laser Fusion,Institute of Nuclear Physics and Chemistry,CAEP,Mianyang 621900,China2. Institute of High Energy Physics,CAS,Beijing 100039,China

Abstract
HTML
Reference
Related

PDF

Abstract：
The calibration of the energy response of the detection elements for soft X-ray spectrometer is reported. The calibration is carried out Beamline 3W1B of Beijing Synchrotron Radiation Facility with beam intensity 40—80mA at electron energy 2.2GeV,using vacuum chamber of reflectometer on An AXUV-100 silicon photodiode is used as the source intensity absolute monitor in the photo energy rang 150—1500eV. The energy response curves for X-ray diode (XRD) quantum efficiency,filter transmittance and grazing planar mirror reflection efficiency have been measured. Finally,the possible maximum errors of the XRD at different energies are given based on these experimental data.

References

[1]

CHANG Tie-Qiang et al.High Power Laser and Particle Beams,1989,1(3):195(in Chinese)(常铁强等.强激光与粒子束,1989,1(3):195)2 Kilkenny J D et al.Diagnostic Systems for the National Ignition Facility.Rev.Sci.Instrum.1995,66(1):2883 CUI Min-Qi et al.High Energy Phys.and Nucl.Phys.,1996,20(9):847(in Chinese)(崔明启等.高能物理与核物理,1996,20(9):847)4 CUI Cong-Wu et al.High Energy Phys.and Nucl.Phys.,1998,22(2):180(in Chinese)(崔聪悟等.高能物理与核物理,1998,22(2):180)5 Henke B L,Smith J A,Attwood D T.J.Appl.Phys.,1977,48(5):18526 Henke B L,Knauer J P,Premaratne K.J.App1.Phys.,1981,52(3):15097 Saloman E B.Nuclear Instruments and Methods,1980,172:79—87
