Surface morphology of He-implanted single-crystalline silicon

Abstract
HTML
Reference
Related

PDF

Abstract：
Single-crystalline Si (100) samples were implanted with 30 keV He²⁺ions to doses ranging from 2.0×10¹⁶to 2.0×10¹⁷ions /cm²and subsequently thermally annealed at 800℃ for 30min. The morphological change of the samples with the increase of implantation dose was investigated using atomic force microscopy (AFM). It was found that oblate-shaped blisters with an average height around 4.0nm were found on the 2.0×10¹⁶ions /cm²implanted sample surface; spherical-shaped blisters with an average height around 10.0nm were found on the 5.0×10¹⁶ions /cm²implanted sample surface; strip-shaped and conical cracks were observed on the sample He-implanted to a dose of 1.0×10¹⁷ions /cm². Exfoliations occurred on the sample surface to a dose of 2.0×10¹⁷ions /cm². Mechanisms underlying the surface change were discussed.

References

[1]

. Tonini R, Corni F, Frabboni S et al. J. Appl. Phys., 1998,84: 48022. Kinomura A, Horino Y, Nakano Y et al. J. Appl. Phys.,2005, 98: 0661023. ZHANG Miao, ZENG Xu-Chu, Chu Paul K et al. J. Appl.Phys., 1999, 86: 42144. Wong-Leung J, Williams J S, Kinomura A et al. Phys. Rew.B, 1999, 59: 79905. Raineri V, Campisano S U. Appl. Phys. Lett., 1996, 69:17836. Raineri V, Campisano S U. Nucl. Instrum. Methods B,1996, 120: 567. Seager C H, Myers S M, Anderson R A et al. Phys. Rew.B, 1994, 50: 24588. Raineri V, Fallica P G, Percolla G et al. J. Appl. Phys.,1995, 78: 37279. Evans J H. Nucl. Instrum. Methods B, 2002, 196: 12510. Avic Ibrahim, Law Mark. E, Kuryliw Erik et al. J. Appl.Phys., 2004, 95: 245211. Fabnroni S, Gazzadi G C, Felisari L et al. Appl. Phys. Lett.,2004, 85: 168312. Muto S, Matsui T, Tanabe T, J. Nucl. Mater, 2001, 290-293: 13113. QIAN C, Terreault B, Gujrathi S C. Nucl. Instrum. Meth-ods B, 2001, 175-177: 71114. Boldyryeva H, Kishimoto N, Umeda N et al. Nucl. Instrum.Methods B, 2004, 219-220: 95315. Oliviero E, Beaufort M F, Barbot J F et al. J. Appl. Phys.,2001, 89: 533216. Raineri V, Co a S, Szilagyi E et al. Phys. Rev. B, 2000,61: 93717. Ziegler J F, Biersack J P, Littmark U. The stopping andrange of Ions in Solids, Vol.1, Pergamon press, New York,198418. Hastings, Estreicher R, Feldman L C et al. Phys. Rev. Lett.,1993, 70: 164319. Freund L B. Appl Phys. Lett., 1997, 70: 351920. Frabboni S, Corni F, Nobili C et al. Phys. Rev. B, 2004,69: 16520921. Moreno D, Eliezer D. Metallurgical and Materials Transac-tions A, 1997, 28: 755

Access

Get Citation

LI Bing-Sheng, ZHANG Chong-Hong, ZHOU Li-Hong and YANG Yi-Tao. Surface morphology of He-implanted single-crystalline silicon[J]. Chinese Physics C, 2008, 32(S2): 255-258.

LI Bing-Sheng, ZHANG Chong-Hong, ZHOU Li-Hong and YANG Yi-Tao. Surface morphology of He-implanted single-crystalline silicon[J]. Chinese Physics C, 2008, 32(S2): 255-258. shu

RIS(for EndNote,Reference Manager,ProCite)

BibTex

Txt

Milestone

Received: 2008-07-17
Revised: 1900-01-01

Article Metric

Article Views(5580)
PDF Downloads(665)
Cited by(0)

Policy on re-use

To reuse of subscription content published by CPC, the users need to request permission from CPC, unless the content was published under an Open Access license which automatically permits that type of reuse.

通讯作者:陈斌, bchen63@163.com

1.
沈阳化工大学材料科学与工程学院沈阳 110142

Surface morphology of He-implanted single-crystalline silicon

Corresponding author:LI Bing-Sheng,

Received Date:2008-07-17
Accepted Date:1900-01-01
Available Online:2008-01-03

Abstract:Single-crystalline Si (100) samples were implanted with 30 keV He²⁺ions to doses ranging from 2.0×10¹⁶to 2.0×10¹⁷ions /cm²and subsequently thermally annealed at 800℃ for 30min. The morphological change of the samples with the increase of implantation dose was investigated using atomic force microscopy (AFM). It was found that oblate-shaped blisters with an average height around 4.0nm were found on the 2.0×10¹⁶ions /cm²implanted sample surface; spherical-shaped blisters with an average height around 10.0nm were found on the 5.0×10¹⁶ions /cm²implanted sample surface; strip-shaped and conical cracks were observed on the sample He-implanted to a dose of 1.0×10¹⁷ions /cm². Exfoliations occurred on the sample surface to a dose of 2.0×10¹⁷ions /cm². Mechanisms underlying the surface change were discussed.
