BEPCⅡ高频屏蔽波纹管纵向耦合阻抗测量和数值计算

Institute of High Energy Physics,CAS,Beijing 100049,China2 Department of Engineer Physics,Tsinghua University,Beijing 100084,China

Abstract
HTML
Reference
Related

PDF

Abstract：
An impedance measurement system has been established to measure the longitudinal coupling impedance of vacuum components for the BEPC upgrade project(BEPCⅡ). The measurement system is based on the traditional coaxial wire methods. The measurements are done in frequency domain taking advantage of the HP/Agilent microwave vector network analyzer 8720ES. Two kinds of techniques, the TRL calibration and using a reference line, were investigated and applied to the practical measurements. This paper introduces this impedance measurement system and the results of the measurements. As a comparison, we also give the numerical simulations of the RF-shielded bellows for BEPCⅡ.
