Chinese Physics C > 1981, Vol. 5 > Issue(4): 452-457

ON THE ANALYSIS OF SEGMENTED RING OF PERMANENT MAGNET MULTIPOLE FIELDS

Abstract
HTML
Reference
Related

PDF

Abstract：
Assuming uniform magnetization of individual magnet pieces, a three dimensional analytical expression for the magnetic field of a newly developed multipole structure of the permanent magnet segmented ring is derived.

References

[1]

Б. П. Мурин, В. И. Рогачев, А. П. Федотов, "О возможности применения квадруполей с постяннтами в Лннейныx ускорителяx протов на высокие энергии" ПТЭ, 19(2)(1976).[2]R. F., Holsinger, "The drift tube and beam line quadrupole permanent magnets for the NEN proton linac"Proton Linear Accelerator Conference (1979).[3]K. Halbach,"Strong rare earth cobalt quadrupoles" IEEE Transaction on nuclear science,June (1979).[4」刘茂三,吴文泰,李淑珍,"永磁透镜场形解析分析及其几何参数选择"(1979年工作总结).[5]Г. И. Будкер, Расчет параметров шимм при исправлеиии локальныx неоднороностей в магнитном полем, Отчет ИЯП АНОССР (1951).[6]И. С. Градштейн, И. М. Рыжин, “Таблицы ннтегралов, сумм, рядов н произведеннй” pp721, 993; 723. (1971) Москва. (Изд. пятое).[7]Н. Н. Лебедев, “Специальные функции и нx приложение” (1949) Москва.[8]刘茂三等,高能物理与核物理.4(1980), 774.
