Chinese Physics C > 2005, Vol. 29 > Issue(10): 989-992

Magnetic Shield for the Vertical Test System of Superconducting Cavity

Institute of High Energy Physics,Chinese Academy of Sciences,Beijing 100049,China

Abstract
HTML
Reference
Related

PDF

Abstract：
In this paper the influence of the space magnetic field on the performance of a superconducting niobium bulk cavity is introduced briefly. And an effective magnetic shielding method for superconducting cavity vertical test is presented. The initial permeabilities of eight different kinds of Fe-Si and Fe-Ni materials at liquid helium or liquid nitrogen temperature has been measured to compare with those at room temperature. The measurement data are given also. Based on it a double layers cylinder magnetic shield has been developed for the cryostat of 1.3GHz superconducting cavity.

References

[1]

. Hasan Padamsee, Jens Knobloch, Tom Hays. RF Superconductivity for Accelerators. New York:Cornell University Ithaca, 1998. 6—72. Aune B, Bandelmann R, Bloess D et al. Superconducting TESLA Cavities. Physical Review Special Topics Accelerators and Beams, 2000, 3: 092001-33. ZHANG Yu-Heng. Superconductivity Physics. Hefei: University of Science and Technology of China Publisher, 1997.250—252(in Chinese)(张玉恒.超导物理.合肥:中国科学技术大学出版社,1997.250-252)4. Hasan Padamsee, Jens Knobloch, Tom Hays. RF Superconductivity for Accelerators. New York:Cornell University Ithaca, 1998. 173—1755. LUO Guo-Hui. Lecture Note for Superconducting RF. The 2nd OCPA Accelerator School. Huangshan, China, July,2000. 11—126. Kenji Saito. Ouick Vertical Test System for L-band Superconducting RF Cavity. Proceeding of the 21st Linear Accelerator Meeting. Tokyo, Japan 1996
