Concept Design of a New Structure of 1.3GHz Single-Cell Superconducting Cavity

Zu Donglin^,

Institute of Heavy Ion Physics, Beijing University, Beijing 100871

Abstract
HTML
Reference
Related

PDF

Abstract：
This paper reported a new shape of practicing single-cell superconducting cavities. It consist of the two half end-cell of 9-cell Beijing TESLA shape accelerating cavity. The ratio of the maximal surface electric field to accelerating gradient,E _p/E _acc,of the π-mode of the 9-cell cavity is reduced to 2.024. The cell -to-cell coupling k is high to 1.95%. The E _p/E _accin the single-cell cavities is reduced to 1.8.The monopole, dipole and quadrupole high-ordermodes, HOM, was calculated with resistance-band model using URMEL-T. In addition, the concept of the structure parameters of niobium cavity was introduced as well as the condition of calculation reliability with codes, URMEL and URMEL-T, was discussed.

References

[1]

V.Lagomarsino iet al/i,IEEE Trans Mag-15（1979）25.[2] P.Kneisel iet al/i,NIM,188（1981）669.[3] C.Lyneis iet al/i,Appl.iPhys/i.iLett/i,31（1977）541.[4] H.Padamsee,A.Joshi,JAppl iPhys/iics,50（1979）1112.[5] D.L.Rubin,Linear Collider Applications of Superconducting RF,thelst TESLA Workshop,23-26July 1990,Cornell UnivUSA.[6] H.Padamseeetal.SuperconductingRFActivitiesatCornellUniversity,Proc.of the 3rd Workshopon RF Supercon ductivity,Argonne,Illinois（1988）,USA.[7] R.M Sundelin,IEEE Transon Nuclear Science,NS-32（1985）3570.[8] Q.S.Shu iet al/i,Reducing Feild Emissionin Superconducting RF Cavities for the Next Generation of Particle Accelerators,CLNS 90/1020,Cornell Univ,（1990）,USA.[9] J.Graberetal,A Would Record Accelrating Gradientina Niobium Superconducting Accelerator Cavity,Proc.of the 1993 IEEEPAC,Wash.DC,p892（1993）[10] TWeil and,NIM.216（1983）329.[11] U.Laustroer,Uvan Riencn,T.Weil and,DESYM-87-03（1987）,Germany.[12] Donglin Zu,Jia-erh Chen,Proc.of the 1993IEEEPAC.Wash.DC,p1095（1993）.[13] K.Halbach,R.F.Holsinger,Part Accel,7（1976）213.[14] Donglin Zu,Summary of URMEL（T）calculationson Crab Cavity, CLNS 91-1090, CU, USA.[15] H. Padarnsee iet al/i, Superconducting RF Accelerating and Crab Cavities for the Cornell B-Factory,CESR-B, CLNS90-1039, internal report of laboratory of iNucl/iear Studies, CU, USA.[16] H. Padamsee iet al/i, Crab Cavity Development for the Cornell B-Factory, CESR-B, PAC. San Francisco.1991.[17] T. Weiland, IEEE Trans. iNucl/i. Sci. NS-32 (1985) 2738.
