A Suitable Material for the Substrate of Micro-Strip Gas Chamber

School of Materials Science & Engineering,Shanghai University,Shanghai 201800,China

Abstract
HTML
Reference
Related

PDF

Abstract：
Micro-strip Gas Chamber (MSGC) used as a position sensitive detector has perfect performances in the detection of nuclear irradiations. However, it encounters a severe problem, that is, positive charge accumulation which can be avoided by reducing the surface resistivity of insulating substrate. So, diamond-like carbon (DLC) film is coated on D263 glass to modify its electrical properties as substrate for MSGC. Raman spectroscopy demonstrates that DLC film is of sp ³(σ bonding) and sp ²bonding (π bonding), and therefore it is a type of electronically conducting material. It also reveals that the film deposited on D263 glass possesses very large of sp ³content and consequently is a high quality DLC film. I-V plots indicate that samples with DLC film enjoy very steady and suitable resistivities in the range of 10 ⁹—10 ¹²Ω·cm. C-F characteristics also show that samples coated by DLC film have low and stable capacitance with frequency. These excellent performances of the new material, DLC film/D263 glass, meet the optimum requirements of MSGC. DLC film/D263 glass used as the substrate of MSGC should effectively avoid the charge pile-up effect and substrate instability and then improve its performances.

References

[1]

. Charpak G et al. Nucl . Instrum. Methods, 1968, A62: 2352. Oed A. Nucl. Instrum. Methods, 1988, A263: 3513. Bouhali O et al. Nucl . Instrum. Methods, 1996, A378: 4234. Bishai M R et al. Nucl. Instrum. Methods, 1997, A400: 2335. Cicoqnani G et al. Nucl. Inst rum. Methods, 1998, A416: 2636. Schmidt S et al. Nucl. Inst rum. Methods, 1994, A344: 5587. YU Zhong-Qiang et al. HEP NP. , 1996, 20( 8) : 6788. ZHANG Ming-Long, XIA Yi-Ben, WANG Lin-Jun. Nucl . Elect r. Det ec. Tech. , 2003, 23( 2) : 1139. Teo K B K et al. Diam. Relat . Mater. , 2002, 11: 108610. Nemanich R J, Lucovsky G, Solin S A. Sol. Stat . Com. , 1977, 23:11711. Meenakshi V, Sayeed A, Subramanyam S V. Mat er. Sci. For. , 1996,223- 224: 30712. Shimakawa K, Miyake K. Phys. Rev. , 1989, B39: 757813. Mack V et al. Nucl. Instrum. Methods, 1995, A367: 173
