Chinese Physics C > 2001, Vol. 25 > Issue(3): 271-276

A Soft Modulating and Double-Scattering Beam Delivery System for Proton Therapy

YU Qing-Chang^,,
XU Tao-Guang

Institute of High Energy Physics, CAS, Beijing 100039, China

Abstract
HTML
Reference
Related

PDF

Abstract：
The proton therapy is a new developing method in the radiation oncology. The superior dose localization capabilities of proton beams suggest the possibility of depositing a higher dose into the cancer while reducing the unwanted radiation damage in surrounding normal tissues. The merit can be realized with the aid of the beam delivery system, whose functions are energy adjustment, energy modulation, beam spreading and collimation. In this paper a new soft-modulating and double-scattering beam delivery system is proposed. It uses a program-controlled modulator to change proton energy and thereby the proton range in the body so that the Bragg peak is spread out. Moreover, a larger treatment field can be obtained with two scatterers. The delivery system has high reliability and flexibility, and is especially good for conformal therapy.

References

[1]

YU Qing-Chang, LUO Zheng-Ming et al. Foundations of Protontherapy Technology Beijing: Atomic Energy Press,1999: 1(in Chinese)(郁庆长, 罗正明等. 质子治疗技术基础. 北京:原子能出版社, 1999:1)2 Coutrakon G, Bauman M, Lesyna D et al. Med. Phys., 1991, 18:10933 Koehler A M, Schneider R J, Sistermn J M. Nucl. Instr. Meth., 1975, 131:4374 Chu W T, Ludewigt B A, Renner T R. Rev. Sci. Instr., 1993, 64:20555 YU Jian-Guo, YU Qing-Chang. High Energy Phys. and Nucl. Phys., 1997, 21:851(in Chinese)(余建国, 郁庆长. 高能物理与核物理, 1997,21:851)6 Pedruni E, Bacher R, Blattmann H et al. Med. Phys., 1995, 22:377 Wilson R R. Phys. Rev. , 1947, 71:3858 Moliere GZ. Naturfomh, 1948, 3a:789 Gottschalk B, Koehler A M, Sisterson J M et al. In: Inter. Proton Radiotherapy Workshop. Switzerland: PSI, 1991.50
