HXMT Magnetic Shield Design and Test Results

Institute of High Energy Physics, CAS, Beijing 100049, China2 Graduate University of Chinese Academy of Sciences, Beijing 100049, China

Abstract
HTML
Reference
Related

PDF

Abstract：
We present the results of experiments on the passive magnetic shield for HXMT main detectors. The magnetic shielding case made of permalloy reduces the maximum gain variations of detectors to 6% on the ground. Together with the automatic gain control system, the magnetic shield system will limit the gain variations of in-flight detectors to 1%, and limit the background variations to 0.1%.
