Chinese Physics C > 2003, Vol. 27 > Issue(9): 831-835

Analysis and Calculation on Electron Bunch Length Measurement by Using CTR

Institute of High Energy Physics, CAS, Beijing 100080,China

Abstract
HTML
Reference
Related

PDF

Abstract：
Measurement of electron bunch length through its generated CTR is a new frequency domain technique developed in the accelerator and FEL fields recently. In this paper we analyze theoretically and calculate numerically CTR produced by a train of RF-linac electron bunches of a few picoseconds at BFEL. For the CTR emitted at wavelengths longer than the bunch length (λ≥2πσz),the intensity is enhanced by a factor of 10 ⁸which is the number of electrons in the bunch; CTR energy is mainly concentrated near the beam axis and can be up to several millijoules for Gaussian and rectangular bunches. A polarized-type Michelson interferometer was designed to measure autocorrelation interferograph of CTR, from which one can diagnose longitudinal length of this bunches and derive its electron density distribution.

References

[1]

. TESLA Technical Design Report.200105,Humberg.20012. LCLS Technical Design Report SLAC-R-593LC 414,April2002 3. Happek U ,Sievers A J.Phys.Rev.Lett,1991,67:2962—29654. Shibata Y ,IshiK ,Takahashi T et al.Phys.Rev.,1992,A45:R8340—83435. Kung P ,Lihn H ,Wiedemann H .Phys.Rev.Lett.,1994,73:967—9706. Tremaine A ,Rosenzweig J B ,Anderson et al.Phys.Rev.Lett.,1998,81:5816—5819 7. Kovachiov G A et al.Nucl.Instr.and Meth.,2000,A448:70—72 8. Watanabe T et al.Nucl.Instr.and Meth.,1999,A437:10—119. Geitz Metal.Nucl.Instr.and Meth.,2000,A445:343—34710. Lumpkin A H et al.Phys.Rev.Lett.,2001,86:79—8211. XIE Jia-Lin.HEP NP ,1994,18:763—766(in Chinese)(谢家麟.高能物理与核物理,1994,18:763—766)12. FrankI M ,Ginsburg V L .J .Physics(Moscow),1945,9:353 13. ZHU Jun-Biao et al.HEP NP ,2000,24(2):172—180(in Chinese)(朱俊彪等.高能物理与核物理,2000,24(2):172—180) 14. ZHU Jun-Biao et al.HEP NP .,2001,25(5):455—460(in Chinese)(朱俊彪等.高能物理与核物理,2001,25(5):455—460)
