Chinese Physics C > 2002, Vol. 26 > Issue(6): 639-644

Analysis of Discharging Noise of Line-Type Pulse Modulator

TAO Xiao-Ping^,

Department of Astronomy and Applied Physics, University of Science and Technology of China, Hefei 230029, China

Abstract
HTML
Reference
Related

PDF

Abstract：
There is high electromagnetic noise radiation in Hefei Light Source (HLS) klystron gallery, which is from pulse discharging of thyratron modulator. This paper expounds the components of discharging circuit of HLS modulator. On the basis of it, the paper analyses the generating of discharging noise of klystron modulator and puts forward the method about reducing discharging noise of klystron modulator.

References

[1]

. The High Pulse Modulator. The Number 8348 Engineering File of Academy of Science of China, NSRL ,19912. DONG Chong. The Theory Basis and Private Circuit of Line-Type Pulse Modulator Beijing:Publishing House of National Defense Industry, 1978(in Chinese).(东冲.线型脉冲调制器的理论基础及专用电路.北京:国防工业出版社.1978) 3. Ott, Henry W. Noise Reduction Techniques in Electronic Systems. 1976 4. Oh J S, Cho M H, Namkung W et al. Efficiency Analysis of The First 111-Mw C- Band Klystron-Modulator for Linear Collider. 1st Asian Particle Accelerator Conference, Tuskuba, Japan, 19985. Oh J S et al. Efficiency Issue in C- band Klystron-Modulator System for Linear Collider, 1997 Particle Accelerator Conference, Vancouver, B. C Canada, May, 1997
