Chinese Physics C > 2001, Vol. 25 > Issue(12): 1231-1237

Study of Ge Thin Heterostructures by Synchrotron Radiation X-Ray Reflection

Institute of High Energy Physics, CAS, Beijing 100039, China2 Surface Physics Laboratory, Fudan University, Shanghai 200433, China

Abstract
HTML
Reference
Related

PDF

Abstract：
Synchrotron radiation X-ray reflection method is used to study the depth distribution of Ge atoms in Si crystals caused by surface segregation during the MBE growth. The distribution of Ge atoms in Si crystal is found to have asymmetric exponential shape by simulating the experimental reflectivity based on X-ray reflection theory and Parratt method. The distribution decay lengths forward and backward along the growth direction are obtained as 8A and 3A, respectively, and do not change with different thicknesses of the Ge layers. The influences on X-ray reflectivity of different parameters, such as the thickness of the Si cap layer, the decay length, the surface roughness, and the thickness of SiO ₂over the surface are discussed briefly.

References

[1]

. CHANG L L ,Ploog K .Molecular Beam Epitaxy and Heterostructures,Martinus Nijhoff Publishers,1985 2. Slijkerman W F J et al.J. Appl.Phys.,1990,68:51053. Izumi K et al.Jpn.J. Appl.Phys.,1993,32:17724. Gossmann H J et al.Appl.Phys.Lett.,1994,64:3125. XIU LiSong et al.Chinese Science Bulletin,1996,41(7):559—562 6. JIANG X ,ZHENG W ,WU J et al.Rev.Sci.Instrum.,1995,66:1694—1695;ZHENG W ,JIANG X et al.Nucl.Instru.and Meth.,1997,B129:543—5477. LU X ,JIANG Z ,HUANG D et al.J. Cryst.Growth,1996,158:1698. JIA Q ,ZHENG W ,WANG Z ,WANG J et al.Acta Physica Sinica(Oversea edition),1998,7:695 9. JIA Quan-Jie,JIANG XiaoMing,JIANG ZuiMin.Physical Testing and Chemical Analysis,PartA :Physical Testing.1998,34(8):3(in Chinese)(贾全杰,姜晓明,蒋最敏.理化检验(物理分册).1998,34(8):3)10. ZHOU X ,and CHEN S .Phys.Rep.,1995,257:223 11. Parratt. Phys.Rev.,1954,95:35912. ZHENG WenLi.Study of Performance of Beamline 4W1C at Beijing Synchrotron Radiation Facility and Study of Ge Thin-layer Structure by Synchrotron Radiation.Master′s Degree Thesis of Institute of High Energy Physics,CAS,2000(in Chinese)(郑文莉.北京同步辐射装置4W1C光束线的性能研究及Si中Ge薄层结构的同步辐射研究. 硕士学位论文,2000)
