AN ION GUN WITH THREE ELECTRODES

Abstract
HTML
Reference
Related

PDF

Abstract：
The formulae of calculating the slop and the radius of the ion beam in the A ₂exit hole and the distance d ₂between the two accelerting electrodes is drived basedon the theory of patallel axis linear optics. The influence of the uniform acceleratingelectric field and the space charge in the A ₁-- A ₂region on the particle trajectory isconsidered. An example is calculated numericaly and compared with analytic results.
