Chinese Physics C > 1981, Vol. 5 > Issue(3): 381-385

DISTRIBUTION OF 2-DIMENSIONAL FIELD OF PERMANENT MAGNETIC PLANE HEAD QUADRUPOLE AND ITS GEOMETRIC PARAMETER SELECTION

Abstract
HTML
Reference
Related

PDF

Abstract：
According to the principle of "Uniform magnetization", the field-shape of plane head quadrupole of "coil replacement" and "Quasi coil replacement" is analysed by means of series expansion. The magnetic field and gradient expression are given in the plane y=0. The optimization relations of height-width ratio of the magnetic piece are also presented.

References

[1]

R. F. Holainger, Proton Linear Acc. Conf., (1979).[2] K.H. Halbach,IEEE, Tr. NS-28 (1979).[3] 刘茂三等,高能物理与核物理,5(1981), 127.[4] 刘茂三等,高能物理与核物理,4(1980), 774.[5] 刘茂三等,定向磁化多体环状永磁多极系统的场形分析.(待发表)[6] N. Saito, E. D. Buca, D. A. Swenaon, 3th In t. Wor, on Rare Earth-Cob. Per. Mag. And App., p.295, (1978).[7] 刘茂三等,“永磁透镜场形解析分极及其几何参数选择”.(工作总结,1979)
