Chinese Physics C > 2007, Vol. 31 > Issue(4): 405-408

Development of the Broadband and Dual-band Cavity Mirrors for SR-FEL at 355nm and 248nm

Institute of Electronics, Chinese Academy of Sciences, Beijing 100080, China2 China Institute of Atomic Energy, Beijing 102413,China

Abstract
HTML
Reference
Related

PDF

Abstract：
The cavity mirrors of the storage-ring free-electron laser (SR-FEL) at 355nm and 248nm central wavelengths have been developed with the technologies of electron-beam evaporation deposition and ion-beam sputter deposition. The mirror coatings consists of “HfO ₂/SiO ₂+Al ₂O ₃/SiO ₂+M-SiO ₂”.The absolute reflectance and frequency-tunable range at 355nm are R=99.45% and Δλ(R≥99.00%)=75nm, respectively, for the broadband resonator mirror. For the mirror with the dual-central wavelengths, R=99.69% and Δλ(R≥99.00%)=59nm for the first band at 355nm; For the second band at 248nm, R=98.21%, Δλ(R≥99.00%)=9nm and Δλ(R≥98.00%)=51nm.

References

[1]

. O'Shea Patrick G, Freund Henry P. Science, 2001, 292:1853-1858.2. Milton S V, Gluskin E, Arnold N D et al. Science, 292:2037-2045.3. YU L H, Babzien M, Ben-Zvi I et al. Science, 2000, 289:932-934.4. Gunster St, Gatto A, Trovo M et al. Proc. 2004FEL Conf.,2004, 233-236.5. GAO Huai-Lin, WANG Nai-Yan, SHAN Yu-Sheng. HEP NP, 2005, 29: 99-103. (in Chinese)(高怀林,王乃彦,单玉生.高能物理与核物理,2005, 29: 99-103)6. Rainer F, Milan D, Lowdermilk W H. NBS Special Publi-cation, 1981, 638: 339-343.7. Gatts A, Heber J, Kaiser N et al. Nuclear Instruments andMethods in Physics Research, 2002, A483: 357-362.8. SHANG S Z, LIAO C Y, YI K et al. High Power Laser Particle Beams, 2005, 17: 511-514.(in Chinese)(尚淑珍,廖春艳,易葵等.强激光与粒子束,2005. 17:511-514)9. GAO Huai-Lin, SHAN Yu-Sheng, WANG Nai-Yan. Chinese J. Laser, 1997, B6: 229-237.
