Study on the Convergent Function of a Cylinder Capillary Transmitting X-Ray

The Key Laboratory of Beam Technology and Material Modification of Ministry of Education, Beijing Normal University, Beijing 100875, ChinaInstitute of Low Energy Nuclear Physics, Beijing Normal University, Beijing 100875, ChinaBeijing Radiation Center, Beijing 100875, China

Abstract
HTML
Reference
Related

PDF

Abstract：
The power density gain and equivalent length of cylinder capillary with different lengths and radii are calculated with a simulation program. In experiment, with 8.04keV X-ray source the power density gain and equivalent length of cylinder capillary are measured and the experiment results are compared with the simulation. The conclusion is drawn that a cylinder capillary has great application prospect on crystal diffraction.
