Design of Pulse Power Supply for CSNS Extraction Kicker Magnet

CHI Yun-Long^,,
WANG Wei

Abstract
HTML
Reference
Related

PDF

Abstract：
A 40kV/6kA pulsed power supply was designed for the Rapid Cycling Synchrotron (RCS) extraction kicker magnet of the China Spallation Neutron Source. The calculation of the pulsed power supply's parameters, the design of power supply's system, the optimization of pulse forming network (PFN) are introduced in this paper. The magnet current pulse waveform is simulated by PSpice program in the situation of 36.5kV charging voltage. The simulation explains the influence of the PFN section number and the transmission cable
length on the magnet current pulse.

References

[1]

. TANG J Y, CHEN Y, CHI Y L et al. Extraction System Design for the CSNS/RCS[A]. Proceedings of 06 European Particle Accelerator Conference [C]. Edinburgh, 20062. ZHANG W, Sandberg J, Hahn H et al. SNS Extraction Fast Kicker Pulsed Power System[A]. Proceedings of 04 European Particle Accelerator Conference [C]. Lucerne, Switzer-land, 20043. DONG C. Transmission Line Type Pulsed Modular Theory Foundation and Special Circuit[M]. Beijing: National Defence Industry Press, 1978(in Chinese)(东冲. 线性脉冲调制器理论基础与专用电路[M]. 北京: 国防业出版社, 1978)
