Chinese Physics C > 1996, Vol. 20 > Issue(4): 376-384

Simulation of RF Thermionic Gun

Department of Engineering Physics,Tsinghua University,Beijing 100084

Abstract
HTML
Reference
Related

PDF

Abstract：
The beam dynamics in RF thermionic guns is studied using simulation method in this paper.A RF thermionic gun simulation code is compiled.It is a versatile multiparticle trace code,besides use for RF thermionic guns,capable of simulations of photocathode RF guns and standing wave accelerators.During our simulation,the Schottky effect and beam load effect are calculated using iterative method, and space charge effect is treated at every time step by splitting the electron bunch into discs of variable radii and considering the mirror effect of the cathode surface.The dynamics calculations are done in a rectangular coordinate system( x, y, z),so that dis-axisymmetrical fields, such as the quadrupole components of RF fields of the coupling slots, can be taken into account.Our simulation results have been compared with those of PARMELA and experiments of BFEL laboratory,showing very good agreement with each other.

References

[1]

G.A.Westensknow,J.M.J Madey,Laser and Particle Beams,2（1984）223.[2]J.S.Fraser,R.L.Sheffield,IEEE Trans.on Nucl.Sc.,NS-32（1985）1791.[3]K.J.Kim,NIM,A275（1985）201.[4]J.Gao,NIM,A304（1991）345.[5]C.Travier,NIM,A340（1994）28.[6]唐传祥、林郁正，用于北京自由电子激光的多腔热阴极微波电子枪的设计与研究，清华大学加速器教研组，内部报告（1994）.[7]B.Mouton,PARMELA,February,6,1989[8]宋燠，强激光与粒子束，3（1991）109.[9]CAV,清华大学加速器教研组，内部资料（1993）.[10]CAV9,清华大学加速器教研组，内部资料（1993）.[11]K.HALBACH,R.F.HOLSINGER,Particle Accelerators,7（1976）213.[12]谢羲等，原子能科学技术，2（1978）127.[13]H.Liu,NIM,A294（1990）365.[14]王钢等，自由电子激光室，私人通信（1995）.
