The Simulation and Experiment Study of a 4 Rod RFQ RF Property

Institute of Heavy Ion Physics,Peking University,Beijing 100871,China

Abstract
HTML
Reference
Related

PDF

Abstract：
A 4-rod RFQ cavity was simulated with MAFIA code for the design of a high current, high duty factor RFQ accelerator. The influence of distance, wide, height and shape of stems on the cavity's RF property were studied. The structure parameters of the RFQ cavity were optimized by the requirements of the shunt impedance and the electromagnetic field distribution in the RFQ accelerator. Based on the simulation result, then a cold cavity model was built, measured and the result was compared with the simulation.
