Simulation and Fabrication Research on X-Band Photonic Band Gap Accelerating Structure

Department of Engineering Physics, Tsinghua University, Beijing 100084, China2 Argonne National Lab, 9700 S Cass Ave, IL 60439, USA

Abstract
HTML
Reference
Related

PDF

Abstract：
Numerical simulation of X-band metallic photonic band gap (PBG) accelerating structure based on a 3D electro-magnetic program is presented. The design of 11.42GHz traveling-wave accelerator has been successfully completed, including the RF-coupler design. At last, the electroforming technique is investigated here, with mechanical tolerances given by simulation.
