Chinese Physics C > 2003, Vol. 27 > Issue(S1): 118-121

X-ray Lithography Technology for the Fabrication of Deep-submicron T-shaped Gate

Microelectronics R&D Center,CAS,Beijing 100029,China2 Synchrotron Radiation Laboratory,Institute of High Energy Physics,CAS,Beijing 100039,China

Abstract
HTML
Reference
Related

PDF

Abstract：
Because of its validity in reducing transistor noise due to gate parasitic resistance,T-shaped structure has been applied for the fabrication of Pseudomorphic High Electron Mobility Transistor (PHEMT) device widely,X-ray lithography is the best way to fabricate deep-submicron T-shaped structure,because it has many adantages,such as large process latitude、high throughput,extremely long depth of focus、large exposure field sizes,low cost,and so on,and the more important thing is that X-ray lithography technology is relatively mature.In this paper,the home-made X-ray mask process is introduced first,and the influence of blur to the light intensity distribution on the surface of X-ray resist is analyzed,the three layer resist method which is used for the fabrication of deep-submicron T-shaped structure and the 75nm T-shaped structure result which was achieved in BSRF 3B1A beamline are presented lastly.

References

[1]

Chen Y, MacIntyre D, Thoms S. Microdnclronic Engineering, 2001,57-58 : 9392 Scott Heetor. J. Vac. Sci. Technol, 1997, B15 (6 ) :25173 Silverman J P. J. Vac. Sci. Technol, 1995 ,B15(6) :21174 Chen A C. J. Vac. Sci. Technol, 1998 ,B16(6) :34855 Yongduck Seo, Ohyun Kim. Jpn. J. Appl. Phys. , Part. 1, 2000,12B :6942
