Design Calculation of a Improved ECR Ion Source

Institute of Modern Physics,Academia Sinica Lanzhou 730000

Abstract
HTML
Reference
Related

PDF

Abstract：
The design of a ECR ion source in a working mode with a ω _ecrresonance surfaces and a 2ω _rfenclosed surface is presented.The 0.8T axial mirror field and 0.8T radial hexapole field are introduced with detailed discussions.The computational results show that the axial length of the ω _ecrresonance surface in the improved ECR ion source is extended significantly compared with the original CAPRICE one and a closed 2ω _rfequigauss surface is also formed.The new topology of the magnetic field in the improved ECR ion source will largely raise the intensity of high charged ion on the basis of the analysis of ionization mechanism.
