Experimental Study of Triple-GEM' Performance and a Multi-channel Image

Lanzhou University, School of Nuclear Science and Technology, Lanzhou 730000, China2 Institute of High Energy Physics, CAS, Beijing 100049, China

Abstract
HTML
Reference
Related

PDF

Abstract：
Experimental study of the performance of triple-GEM and a multi-channel image was reported. The measured experimentally best energy resolution of ⁵⁵Fe 5.9keV X-ray full energy photo electron peak is 20.2%, effective gain ≥10 ⁴. Image was obtained by using 96 channels digital DAQ system which was composed of 96 8mm×8mm pads and 96 electronics channels.
