INFLUENCE OF THE SHAPE OF THE POLE EDGE ON THE PERFORMANCE OF SINGLE-DIRECTION SWEEPING MAGNET

YU Qing-Chang^,,
CAI Ren-Kang

Institute of High Energy Physics,Academia Sinica,Beijing1 Applied Radiation Institute,Shanghai University of Science and Technology

Abstract
HTML
Reference
Related

PDF

Abstract：
In this paper the influence of the shape of the exit edge of the single-direction sweeping magnet of its performance is studied.The proper change of the shape of exit edge can improve the sweeping homogeneous degree and decrease unfavourable focusing effect of the magnet.
