Chinese Physics C > 2004, Vol. 28 > Issue(3): 321-324

Performance Improvement of the Low Energy Branch of 4B9B Beamline in BSRF

Institute of High Energy Physics,CAS,Beijing 100039,China

Abstract
HTML
Reference
Related

PDF

Abstract：
B9B is a soft X-ray beamline in Beijing Synchrotron Radiation Laboratory, the photon energy range is 10-1000eV, photon energy of the low energy branch is from 10-60eV, mainly for angle resolved photoemission spectrum. Within years operation, some experiments were limited by the poor coumt-rate. This article analyzed the shortcomings on the design of the low energy branch, introduced a new scheme of beamline upgrade which need to change two focusing mirrors, meanwhile the mirror parameters was calculated and tracing results of the new beamline was presented. During SR beam time, performance of the beamline was tested after the improvement work, which shows a much more smaller focused image on sample position, and meanwhile the count-rate of experiments with upgraded are increased by more than one order. The beamline is put into use after the upgrade.

References

[1]

. Edited by Institute of High Energy Physics.Research Report of Beijing Synchrotron Radiation Facility,National Laboratory of Beijing Electron Positron Collider,1992.1(in Chinese)( 编辑.北京同步辐射装置研制报告,北京正负电子对撞机国家实验室,1992.1)2. SHU De-Ming et al.Files of 4B9B Beamline.Institute of High Energy Physics,CAS,1990(in Chinese)(舒德明等.同步辐射4B9B束线档案. ,1990)3. Koch E E,Eastman D E,FargeY.Handbook on Synchrotron Radiation,1983,1A 4. WANG Jian-Qi,WU Wen-Hui et al.Introduction To Electrons pectrum(XPS/XAES/UPS),Beijing:Natinal Defence Industry Press,1992(in Chinese)(王建棋,吴文辉等.电子能谱学(XPS/XAES/UPS)引论.北京:国防工业出版社,1992) 5. VSW Scientific Instruments Corporation.VSW Instruction Manual on HA54 Hemispherical Analyzer,1989
