Accurate Computation on High Order Modes of Axial-symmetric Cavity with Vector Finite Element Method

WEI Shi^,,
LIN Yu-Zheng

Dpartment of Engineering Physics, Tsinghua University, Beijing 100084, China

Abstract
HTML
Reference
Related

PDF

Abstract：
Eigenfrequencies of high order modes in the axial-symmetric cavities are computed with a vector finite element method. Mathematics models and physics theories are combined in a rational way, which avoids the spurious modes caused by ordinary finite element methods. Using quadratic scalar and vector basis functions, high accuracy of results are available with few meshes. A code named Cafe is presented. It provides a good base for further research of wakefields of the detuned structures in next generation linear collider.
