Chinese Physics C > 2006, Vol. 30 > Issue(8): 780-783

I/Q Methods Applied to Phase Detection of RF Signals

Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China2 Shanghai Institute of Applied Physics, Chinese Academy of Sciences, Shanghai 201800, China

Abstract
HTML
Reference
Related

PDF

Abstract：
Phase detection performs a crucial role in the phase control loop of RF signals in accelerators. This paper presents two methods that apply I/Q technique to phase detection of RF signals. The content includes the study of arithmetic and the setup of systems. The methods are as follows: 1. adopting I/Q demodulator, AD card and the technique of digital processing to detect the phase; 2. direct digital I/Q method. In the former, feasible calibration arithmetic against the inherent error of I/Q demodulators is suggested. In the latter, I and Q signals are generated by modulating the LO signal with a step of(2π/N). The phase detection error is below 0.5° by using either of them.

References

[1]	. LIU Yong-Tan et al. Radar Imagery Technology. Harbin:Harbin Institute of Technology Press, 1999(in Chinese)(刘永坦等著.雷达成像技术.哈尔滨:哈尔滨上业大学出版社,1999)2. Ellingson S W. Correcting I-Q Imbalance in Direct Conversion Receivers
