Chinese Physics C > 1988, Vol. 12 > Issue(1): 80-84

THE FINITE ELEMENT ANALYSIS OF EDDY-CURRENT FIELDS OF A C-TYPE SOLID YOKE BENDING MAGNET

University of Science and Technology of China,Hefei2 Institute of High Energy Physics,Academia Sinica,Beijing

Abstract
HTML
Reference
Related

PDF

Abstract：
The finite element method developed recent years and used for solving two-dimensional timedependent magnetic fields is introduced.Using this method,we have calculated the eddycurrent fields of a C-type solid yoke bending magnet which is a model magnet of the 800MeV electron storage ring in Hefei.The calculation results are in agreement with measurements.The possibility of applying a solid yoke bending magnet in the case of slow acceleration is discussed.

References

[1]	B. Aldefeld"A Numerical Solution of Transient Nonlinear Eddy-Current Problems Including Moving Iron Parts" INTERMAN Conference 1978, France.[2] J. A.MacBain "A Numerical Analysis of Time-Dependent Two-Dimensional Magnetic Fields" IEEE Vol.MAG-17, No. 6,1981.[3] 裴国玺等, 高能物理与核物理, 10(1986), 578.
