Chinese Physics C > 2005, Vol. 29 > Issue(8): 793-796

Accurate Computation on High Order Modes of Axial-symmetric Cavity with The Third Order Vector Finite-Element Method

CAO Liang^,,
HUANG Wen-Hui

Department of Engineering Physics,Tsinghua University,Beijing 100084,China2 Department of Mathematical Sciences,Tsinghua University,Beijing 100084,China

Abstract
HTML
Reference
Related

PDF

Abstract：
In this paper, the third order vector finite-element method is presented which achieves remarkable improvement on the precision of numerical computation for high order modes of RF cavities. Compared with Cafe , which is a numerical computing program for high order modes of axial-symmetric cavities employing the second order vector finite-element method, our method is quicker and more precise in computing curve boundaries. Thus the program meshmatrix3 is obtained for computing high order modes of axial-symmetric cavities with the third order vector finite-element method. It is shown that our meshmatrix3 works satisfyingly.

References

[1]

. ZHAN Xiao-Wei .Transverse Wakefield Analysis for the NLCJLC De-tuned Structures on a Parallel Computer. In: National Accelerator Facilityed. Computat ional Accelerator Physics. Virginia: Williamsburg Press,1997.2. WEI Shi , LIN Yu-Zheng. HEPNP, 2001, 25 (10) : 1017 -1021(in Chinese)(韦石，林郁正.高能物理与核物理，2001,25(10):1017-1021)3. Eric Michael Nelson. High Accuracy Electromagnetic Field Solvers for Cylindrical Waveguides and Axisymmet ric Structures Using the Finit eElement Method: SLAC-R-431. Stanford University, 19934. YANG Shao-Qi. Sparse Matrices Algorithm and Programming. Beijing:Higher Educat ion Press, 1985(in Chinese)(杨绍祺.稀疏矩阵算法及程序实现.北京:高等教育出版社，1985)5. Roger G Grimes, John G Lewis, Horst D Simon. Siam J. Matrix Anal.Appl . , 1994, 15(1) : 1 - 45
