Chinese Physics C > 2017, Vol. 41 > Issue(6): 067001 DOI: 10.1088/1674-1137/41/6/067001

Development of fundamental power coupler for C-ADS superconducting elliptical cavities

1.
Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China
2.
University of Chinese Academy of Sciences, Beijing 100049, China
3.
Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China

Abstract
HTML
Reference
Related

PDF

Abstract：
5-cell elliptical cavities have been selected for the main linac of the China Accelerator Driven sub-critical System (C-ADS) in the medium energy section. According to the design, each cavity should be driven with radio frequency (RF) energy up to 150 kW by a fundamental power coupler (FPC). As the cavities work with high quality factor and high accelerating gradient, the coupler should keep the cavity from contamination in the assembly procedure. To fulfil the requirements, a single-window coaxial type coupler was designed with the capabilities of handling high RF power, class 10 clean room assembly, and heat load control. This paper presents the coupler design and gives details of RF design, heat load optimization and thermal analysis as well as multipacting simulations. In addition, a primary high power test has been performed and is described in this paper.
- superconducting elliptical cavity,
- fundamental power coupler,
- high power,
- clean assembly,
- heat load

References

[1]	Z. C. Liu, J. Gao, Z. Q. Li et al, Chinese Physics C, 37 (01): 017005 (2013)
[2]	Z. H. Li, P. Cheng H. P. Geng et al, Phys. Rev. ST Accel. Beams, 16: 080101 (2013)
[3]	S. Belomestnykh, Overview of Input Power Coupler Developments, Pulsed and CW, in Proceedings of SRF2007 (Beijing, China, 2007)
[4]	B. Dwersteg, D. Kostin, M. Lalayan et al, TESLA RF Power Couplers Development at DESY, in Proceedings of the 10th Workshop on RF Superconductivity (Tsukuba, Japan, 2001)
[5]	J. Knobloch, W. Anders, M. Martin et al, CW Operation of the TTF-III Input Couple, in Proceedings of 2005 Particle Accelerator Conference (Knoxville, Tennessee, USA, 2005)
[6]	V. Veshcherevich, S. Belomestnykh, P. Quigley et al, High Power Tests of First Input Couplers for Cornell ERL Injector Cavities, in Proceedings of 2007 IEEE Particle Accelerator Conference, (Albuquerque, New Mexico, USA, 2007)
[7]	E. Kako, S. Noguchi, T. Shishido et al, High Power Tests of CW Input Couplers for CERL Injector Cryomodule, in Proceedings of IPAC2012 (New Orleans, Louisiana, USA, 2012)
[8]	Q. S. Shu, J. Susta, G.F. Cheng, Design and fabrication of input RF coupler windows for the U. S. rare isotope accelerator project (RIA), in Proceedings of the 11th Workshop on RF Superconductivity (Lbeck/Travemnder, German, 2003)
[9]	M. Stirbet, K. M. Wilson, M. Wiseman et al, RF Conditioning and Testing of Fundamental Power Couplers for SNS Superconducting Cavity Production, in Proceedings of 2005 Particle Accelerator Conference (Knoxville, Tennessee, 2005)
[10]	W. C. Xu, Z. Altinbas, S. Belomestnykh et al, Phys. Rev. ST Accel. Beams, 15: 072001 (2012)
[11]	P. Paolo, Fundamental of Cryogenics (for superconducting RF technology), in Proceedings of CAS-CERN Accelerator School: Course on High Power Hadron Machines, edited by R. Bailey (Geneva: CERN, 2013), p. 349-368
[12]	T. M. Huang, W. M. Pan, Q. Ma et al, Nuclear Instruments and Methods in Physics Research A, 623: 895-902 (2010)
[13]	S. P. Li, R. Ge, Z. Zhang et al, Overall design of the ADS Injector I cryogenic system in China, in Proceedings of 25th International Cryogenic Engineering Conference and International Cryogenic Materials Conference (Enschede, Netherlands, 2014)
[14]	Y. M. Li, A. Sun, L. P. Zhang et al, MultiPac 2.1-Multipacting Simulation Package with a 2D FEM Field Solver for a Microsoft Windows System, in Proceedings of EPAC2008 (Genoa, Italy, 2008)
