An ultrafast front-end ASIC for APD array detectors in X-ray time-resolved experiments

1.
Beijing Synchrotron Radiation Facility, Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China
2.
State Key Laboratory of Particle Detection and Electronics, Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China

Abstract
HTML
Reference
Related

PDF

Abstract：
An ultrafast front-end ASIC chip has been developed for APD array detectors in X-ray time-resolved experiments. The chip has five channels: four complete channels and one test channel with an analog output. Each complete channel consists of a preamplifier, a voltage discriminator and an open-drain output driver. A prototype chip has been designed and fabricated using 0.13 μm CMOS technology with a chip size of 1.3 mm×1.9 mm. The electrical characterizations of the circuit demonstrate a very good intrinsic time resolution (rms) on the output pulse leading edge, with the test result better than 30 ps for high input signal charges (> 75 fC) and better than 100 ps for low input signal charges (30-75 fC), while keeping a low power consumption of 5 mW per complete channel.
- time-resolved,
- APD,
- ASIC,
- synchrotron X-ray

References

[1]	Makoto Seto, J. Phys. Soc. Jpn, 82: 021016 (2013)
[2]	G. V. Smirnov, Hyperfine Interactions, 97: 551-588 (1996)
[3]	Da-Rui Sun, Guang-Lei Xu, Bing-Bing Zhang et al, J. Synchrotron Rad, 23: 830-835 (2016)
[4]	Shunji Kishimoto, Rev. Sci. Instrum, 66: 603-605 (1995)
[5]	Shunji Kishimoto, J. Synchrotron Rad, 5: 275-279 (1998)
[6]	A. Q. R. Baron, Nucl. Instrum. Methodes Phys. Res. A, 343: 517-526 (1994)
[7]	A. Q. R. Baron, R. Rffer and J. Metge, Nucl. Instrum. Methodes Phys. Res. A, 400: 124-132 (1997)
[8]	A. Q. R. Baron. Hyperfine Interactions, 125: 29-42 (2000)
[9]	F. Anghinolfi, P. Jarron, F. Krummenacher et al, IEEE Transactions on Nuclear Science, 51: 1974-1978 (2004)
[10]	M. Despeisse, F. Powolny, P. Jarron et al, IEEE Transactions on Nuclear Science, 58: 202-208 (2011)
[11]	M. Ciobanu, N. Herrmann, K. D. Hildenbrand et al, IEEE Transactions on Nuclear Science, 61: 1015-1023 (2014)
[12]	Ramn Gonzlez Carvajal, Jaime Ramrez-Angulo, Antonio J. Lpez-Martn et al, IEEE Transactions on Circuits and Systems I: Regular Papers, 52: 1276-1291 (2005)
[13]	Sarpeshkar, Rahul, Tobias Delbruck, and Carver A. Mead, IEEE Circuits and Devices Magazine, 9: 23-29 (1993)
[14]	X. Zhou, Z. Deng, Y. Wang et al, Journal of Instrumentation, 9: C10040 (2014)
[15]	J. Kataoka, T. Saito, Y. Kuramoto et al, Nucl. Instrum. Methodes Phys. Res. A, 541: 398-404 (2005)
[16]	A. Nassalski, M. Moszynski, A. Syntfeld-Kazuch et al, Application of Hamamatsu S8550 APD array to the Common PET/CT Detector, 2007 IEEE Nuclear Science Symposium Conference Record, Hawaii, USA, Oct. 27-Nov. 3, 2007
