Chinese Physics C > 2017, Vol. 41 > Issue(5): 056101 DOI: 10.1088/1674-1137/41/5/056101

Beam test of CSES silicon strip detector module

University of Chinese Academy of Sciences (UCAS), Beijing 100049, China;
2. Institute of High Energy Physics (IHEP), Chinese Academy of Sciences (CAS), Beijing 100049, China

Abstract
HTML
Reference
Related

PDF

Abstract：
The silicon-strip tracker of the China Seismo-Electromagnetic Satellite (CSES) consists of two double-sided silicon strip detectors (DSSDs) which provide incident particle tracking information. A low-noise analog ASIC VA140 was used in this study for DSSD signal readout. A beam test on the DSSD module was performed at the Beijing Test Beam Facility of the Beijing Electron Positron Collider (BEPC) using a 400-800 MeV/ cproton beam. The pedestal analysis results, RMSE noise, gain correction, and intensity distribution of incident particles of the DSSD module are presented.
