Measurement of the transfer function for a spoke cavity of C-ADS Injector I

1.
University of Chinese Academy of Sciences, Beijing 100049, China
3.
4.

Abstract
HTML
Reference
Related

PDF

Abstract：
The spoke cavities mounted in the China Accelerator Driven sub-critical System (C-ADS) have high quality factor ( Q) and very small bandwidth, making them very sensitive to mechanical perturbations, whether external or self-induced. The transfer function is used to characterize the response of the cavity eigenfrequency to the perturbations. This paper describes a method to measure the transfer function of a spoke cavity. The measured Lorentz transfer function shows there are 206 Hz and 311 Hz mechanical eigenmodes excited by Lorentz force in the cavity of C-ADS, and the measured piezo fast tuner transfer function shows there are 12 mechanical eigenmodes from 0 to 500 Hz. According to these results, some effective measures have been taken to weaken the influence of helium pressure fluctuation, avoid mechanical resonances and improve the reliability of the RF system.
- Spoke012,
- Lorentz transfer function,
- piezo fast tuner transfer function,
- mechanical eigenmodes
