Chinese Physics C > 2017, Vol. 41 > Issue(2): 026102 DOI: 10.1088/1674-1137/41/2/026102

System design for precise digitization and readout of the CSNS-WNS BaF₂spectrometer

De-Liang Zhang^1,2,
Ping Cao^1,3,,,
Qi Wang^1,2,
Bing He^1,3,
Ya-Xi Zhang^1,2,
Xin-Cheng Qi^1,3,
Tao Yu^1,2,
Qi An^1,2

1.
State Key Laboratory of Particle Detection and Electronics, University of Science and Technology of China, Hefei 230026, China
2.
Department of Modern Physics, University of Science and Technology of China, Hefei 230026, China
3.
School of Nuclear Science and Technology, University of Science and Technology of China, Hefei 230027, China

Abstract
HTML
Reference
Related

PDF

Abstract：
The BaF ₂(barium fluoride) spectrometer is one of the experiment facilities at the CSNS-WNS (White Neutron Source at China Spallation Neutron Source), currently under construction. It is designed to precisely measure the (n, γ) cross section, with 92 crystal elements and complete 4π steradian coverage. In order to improve the precision of measurement, in this paper, a new precise digitization and readout method is proposed. Waveform digitizing with 1 GSps sampling rate and 12-bit resolution is used to precisely capture the detector signal. To solve the problem of massive data readout and processing, the readout electronics is designed as a distributed architecture with 4 PXIe crates. The digitized signal is concentrated to the PXIe crate controller through a PCIe bus on the backplane and transmitted to the data acquisition system over gigabit Ethernet in parallel. Besides, the clock and trigger can be fanned out synchronously to every electronic channel over a high-precision distribution network. Test results show that the prototype of the readout electronics can achieve good performance and meet the requirements of the CSNS-WNS BaF ₂spectrometer.
- CSNS-WNS BaF2 spectrometer,
- readout electronics,
- waveform digitizing,
- clock and trigger network

References

[1]	J. Y. Tang, S. N. Fu, H. T. Jing et al, Chin. Phys. C, 34(1):121-125(2010)
[2]	K. Wisshak, K. Guber, F. Kppeler et al, Nucl. Instrum. Methods Phys. Res., Sect. A, 292(3):595-618(1990)
[3]	R. Reifarth, T. A. Bredeweg, A. Alpizar-Vicente et al, Nucl. Instrum. Methods Phys. Res. A, 531(3):530-543(2013)
[4]	C. Guerrero, U. Abbondanno, G. Aerts et al, Nucl. Instrum. Methods Phys. Res. A, 608(3):424-433(2009)
[5]	G. Z. He, Study on (n, ) Reaction Cross Section Measurement with BaF2 Scintillation Detector, Ph. D. Thesis (Lanzhou:Lanzhou University, 2006) (in Chinese)
[6]	J. Wei, Modern Physics, 19(6):22-29(2007)
[7]	J. M. Wouters, A. A. Vicente, T. A. Bredeweg et al, IEEE Trans. Nucl. Sci., 53(3):880-885(2006)
[8]	U. Abbondanno, G. Aerts, F. Alvarez et al, Nucl. Instrum. Methods Phys. Res., Sect. A, 538(1):692-702(2005)
[9]	J. L. Yuan, GTAF System's Front-end Electronics' Design and Performance Testing and System of the Target Switch's Development, M.S. Thesis (Lanzhou:Lanzhou University, 2008) (in Chinese)
[10]	D. L. Zhang, Signal Readout Method for CSNS-WNS BaF2 Spectrometer, Ph. D. Thesis (Hefei:University of Science and Technology of China, 2016) (in Chinese)
[11]	TI. Specification, ADC12D100
[12]	TI. Specification, LMK04821
[13]	NI. Specifications, Crate NI-1085
[14]	B. He, P. Cao, D. L. Zhang et al, arXiv:1602.06635
