Chinese Physics C > 2016, Vol. 40 > Issue(9): 096204 DOI: 10.1088/1674-1137/40/9/096204

Dead cell and side leakage correction for a lead-scintillating fiber electromagnetic calorimeter

Abstract
HTML
Reference
Related

PDF

Abstract：
The electromagnetic calorimeter (ECAL) of the Alpha Magnetic Spectrometer (AMS-02) is one of the key detectors for dark matter searches. It measures the energies of electrons, positrons and photons and seperates them from hadrons. Currently, there are 5 dead cells in the ECAL, which affect the reconstructed energy of 4.2% of total events in the ECAL acceptance. When an electromagnetic shower axis is close to the ECAL border, due to the side leakage, the reconstructed energy is affected as well. In this paper, methods for dead cells and side leakage corrections for the ECAL energy reconstruction are presented. For events with the shower axis crossing dead cells, applying dead cell correction improves the difference in the reconstructed energy from 12% to 1%, while for events near the ECAL border, with side leakage correction it is improved from 4% to 1%.
- AMS-02,
- ECAL,
- dead cell correction,
- side leakage correction

References

[1]	R. Battiston et al, Astropart. Phys.,13:51-74(2000)
[2]	Th. Kirn, Nucl. Instrum. Methods A, 706C:43(2013); Ph. Doetinchem et al, Nucl. Instrum. Methods A, 558:526(2006); F. Hauler et al, IEEE Trans. Nucl. Sci, 51:1365(2004)
[3]	B. Alpat et al, Nucl. Instrum. Methods A, 613:207(2010)
[4]	A. Basili et al, Nucl. Instrum. Methods A, 707:99(2013); V. Bindi et al, Nucl. Instrum. Methods A, 623:968(2010)
[5]	K. Luebelsmeyer et al, Nucl. Instrum. Methods A, 654:639(2011); M. Aguilar et al, Phys. Rep., 366(6):331(2002)
[6]	Ph. Doetinchem et al, Nucl. Phys. B, 197:15(2009)
[7]	M. Aguilar-Benitez et al, Nucl. Instrum. Methods A, 614:237(2010); P. Aguayo et al, Nucl. Instrum. Methods A, 560:291(2006); B. Baret et al, Nucl. Instrum. Methods A, 525:126(2004); J. Casaus, Nucl. Phys. B (Proc. Suppl.), 113:147(2002).
[8]	C. Adloff et al, Nucl. Instrum. Methods A, 714:147(2013)
[9]	F. Cadoux et al, Nuclear Physics B, 113(Proc.Suppl.):159-165(2002)
[10]	Z. Li et al, Chinese Physics C, 38(05):056203(2014)
[11]	Z. Li et al, Chinese Physics C, 37(02):026201(2013)
[12]	J. Allison et al, IEEE Trans. Nucl. Sci, 53:270(2006); S. Agostinelli et al, Nucl. Instrum. Methods A, 506:250(2003)
[13]	E. Longo and Sestili I, Nucl. Instrum. Methods, 128:283(1975)
[14]	G. Grindhammer et al, arXiv:hep-ex/0001020
[15]	Z. Li et al, HEPNP, 28:1188-1192(2004)(in Chinese)
