Fast control latency uncertainty elimination for the BESIII ETOF upgrade

Yun Wang^1,2,
Ping Cao^1,2,,,
Shu-bin Liu^1,3,
Qi An^1,2

Abstract
HTML
Reference
Related

PDF

Abstract：
A new fanning topology is proposed to precisely fan out fast control signals in the Beijing Spectrometer (BESIII) end-cap time-of-flight (ETOF) electronics. However, uncertainty in transfer latency is introduced by the new fanning channel, which will degrade the precision of fast control. In this paper, latency uncertainty elimination for the BESIII ETOF upgrade is introduced. The latency uncertainty is determined by a Time-Digital-Converter (TDC) embedded in a Field-Programmable Gate Array (FPGA) and is eliminated by re-capturing at synchronous and determinate time. Compared with the existing method of Barrel-cap TOF (BTOF), it has advantages of flexible structure, easy calibration and good adaptability. Field tests on the BESIII ETOF system show that this method effectively eliminates transfer latency uncertainty.
- transfer latency uncertainty,
- SerDes,
- BESIII,
- endcap TOF
