Design of a 325 MHz half wave resonator prototype at IHEP

1.
University of the Chinese Academy of Sciences, Beijing 100049, China
2.
Institute of High Energy Physics, CAS, Beijing 100049, China
3.
University of the Chinese Academy of Sciences, Beijing 100049, China
4.
Institute of High Energy Physics, CAS, Beijing 100049, China

Abstract
HTML
Reference
Related

PDF

Abstract：
A 325 MHz β=0.14 superconducting half-wave resonator prototype has been developed at the Institute of High Energy Physics, Beijing, which can be applied in the low energy section of continuous wave high current proton linear accelerators. The electromagnetic design, multipacting simulation, mechanical optimization and fabrication are introduced in detail. Test results at room temperature and 4.2 K, and a comparison between measured and simulated results, are analyzed in this paper.
- low beta HWR,
- high beam proton accelerator,
- vertical test

References

[1]	S. Nagaitsev, S. Holmes et al. The Project-X Injector Experiment:a Novel High Performance Front-endfora Future High Power Proton Facility at Fermilab, Proceedings of PAC2013, Pasadena, CA USA, 2013
[2]	E. Zaplatin, P. Bosland et al, IFMIF-EVEDA SC =0.094 Half-wave Resonator Study, Proceedings of SRF2009, Berlin, Germany, 2009
[3]	M. Leitner, B. Bird et al, The FRIB Projectat MSU, Proceedings of SRF2013, Paris, France, 2013
[4]	WANG Zhijun, HE Yuan et al, Chinese Physics C, 36(3): 256-260 (2012)
[5]	G. Park, H.C. Jung et al, Design of HWR at RISP, Proceedings of IPAC2013, Shanghai, China, 2013
[6]	J. P. Holzbauer, J. Binkowski et al, Coupled Electromagnetic and Mechanical Simulations for Half-wave Resonator Design, Proceedings of SRF2011, Chicago, IL USA, 2011
