Chinese Physics C > 2016, Vol. 40 > Issue(8): 087002 DOI: 10.1088/1674-1137/40/8/087002

A method for designing a variable-channel high-power cavity combiner

1.
National Synchrotron Radiation Laboratory, University of Science and Technology of China, Hefei 230029, China

Abstract
HTML
Reference
Related

PDF

Abstract：
Cavity combiners have been put forward for high power combining due to their advantages of larger combining ability, variable input channels and less power loss. For a high power cavity combiner, it is better to keep the power loss ratio in a reasonable range, because large power loss would lead to strict requirements on the cooling system. A combiner with variable input channels is convenient for outputting different power levels according to practical demands. In this paper, a method for designing a variable-channel high-power cavity combiner is proposed, based on the relation between input and output coupling coefficients obtained by analyzing the equivalent circuit of the cavity combiner. This method can put the designed cavity combiner in a matching state and keep its power loss rate in a reasonable range as the number of input channels changes. As an example, a cavity combiner with 500 MHz and variable input channels from 16 to 64 is designed, and the simulation results show that our proposed method is feasible.
- cavity combiner,
- variable channels,
- equivalent circuit,
- coupling coefficient

References

[1]	P. Marchand, T. Ruan, F. Ribeiro et al, Phys. Rev. ST Accel. Beams, 10: 112001 (2007)
[2]	P. Marchand, M. Louvet, K. Tavakoli et al, Successful RF and Cryogenic Tests of the SOLEIL Cryomodule, in Proceedings of the 21st Particle Accelerator Conference (Tennessee: PAC'05 ORNL/SNS, 2010), p. 3438
[3]	J. Jacob, J.-M. Mercier, M. Langlois et al, 352.2 MHz-150 KW Solid State Amplifiers at The ESRF, in Proceedings of the 2nd International Particle Accelerator Conference (San Sebastian: IPAC'11 EPS-AG, 2011), p. 71
[4]	Bravo, B, Mares, F and Perez et al, CACO: A CAVITY COMBINER FOR IOT AMPLIFIERS, in Proceedings of the 2nd International Particle Accelerator Conference (San Sebastian: IPAC'11 EPS-AG, 2011), p. 181
[5]	J. Jacob, L. Farvacque, G. Gautier et al, Commissioning of First 352.2 MHz-150 kW Solid State Amplifiers at the ESRF and Status of RD, in Proceedings of the 4th International Particle Accelerator Conference (Shanghai: IPAC'13 OC/SPC, 2013), p. 2708
[6]	Thomas P. Wangler, RF linear accelerators (2nd edition, John Wiley Sons, Inc., 2008), p. 145
[7]	David M. Pozar, Microwave engineering (Fourth edition, John Wiley Sons, Inc., 2009)
[8]	Rajesh Kumar, P. Singh, Divya Unnikrishnan et al, Nucl. Instrum. Methods A, 481: 203-213 (2012)
[9]	J. Gao, Nucl. Instrum. Methods A, 664: 36-42 (2002)
[10]	V. Khoruzhiy, arXiv:1305.3770, (2013)
[11]	J. Corlett, Derun Li, and A. Mitra, A 35 MHz re-buncher RF cavity for ISAC at Triumf, in Proceedings of the 6th European Particle Accelerator Conference (Stockholm: EPAC'98 IOP/Ltd, 1998), p. 1790
